Prona-R-1500
Product Code: Prona-R-1500Share
Air-Powered Double Diaphragm Pumps
Details:
*R Series: Aluminium Alloy RS Series:Stainless Steel PP Series: Plastic
*Normal: Use USS Ceramic: Use OSO Casting Industries: Use ONO Strong PH: Use OTO
| Alumium Alloy Pump Series R-1500 | ||||
| Fluid Input Size | (3/8inch) | Maximum Pump Speed | 500 cpm | |
| Max. Pressure | 7 bar | Each Cycle Capacity | 0.08 L | |
| Fluid Input Size | 3/8”NPT | Max. Air Consumption Capacity | 200 ml/min | |
| Air Input Size | 1/4″NPT | Particle Maximum Diameter | ∅2 mm | |
|
Min. Starting Pressure
|
Planar Valve | 1.6 bar | Lift Range |
6.4 m Wet- 3.7mDry
|
| Low-Pressure Valve | 0.5 bar | Net Weight | 9kg | |
| Max. Passage Amount | 9.37 G.P.M(36 LPM) | Carton Box Size (cm) | 41x28x48 | |
